Pipe Stress Analysis and Support design for Process, Power, Services Buildings Piping and Pipelines

The objective of pipe stress analysis is to check the piping or pipelines of various industries for operating & occasional loads. The piping network are then designed, that can withstand these loads & forces. Purpose of analysis is to determine the stresses, deflection & forces in pipelines in design as well as operating condition. Based on analysis results, various design modifications like flexible connectors, rigid anchors, additional supports, spring hangers are suggested. Stress analysis is conducted to come up with innovative design solutions that meet international code compliances like IBC, UBC, BS, ASME, CSA, FEMA, API 618 and API 674. Design of structural steel supports for various piping systems are designed using FEM. These supports are designed using NBCC & ASCE.


Modeling & Analysis:

The 3D modeling for the entire piping or pipeline network with all the bends and runs along with initial support locations are captured and modeled using pipe stress analysis software Such as CAESAR II or Bentley-AutoPIPE.

The piping system are appropriately modeled accounting for their loss coefficient and elevation. The analysis shows the displacement for the pipes at different locations and also the stresses caused due to operating & occasional loads. Various combinations of loading on the piping or pipeline are provided as per applicable standards, which includes:

Pipe Stress Analysis and Support design for Process, Power, Services Buildings Piping and Pipelines. Located in Calgary, Alberta; Vancouver, BC; Toronto, Ontario; Buena Park, California; We offer our Piping Engineering Services, Skid Design Services, Pipeline Engineering Services and Structural Engineering Services across Canada. To get our Piping Stress Analysis Services, please contact our Engineering company.  Our professional piping stress engineers have a bachelor's and Masters degree in mechanical / structural engineering and province license (P.Eng.) in Alberta, Saskatchewan, British Columbia and Ontario. We review, validate, certify and stamp piping and structural packages. Also check Industries We Serve.  We provide premium piping engineering & full-service pipe design and pipeline / pipe stress analysis services, from initial concept through final construction. We serve all types of industries across Canada & globally. Using CAESAR II and pipe stress calculations as per API, ASME B31.3, B31.1, B31.8, B31.4, B31.9, CSA Z662.
  • Dead load

  • Pressure Load

  • Thermal Load

  • Seismic loads

  • Wind loads

  • Water hammer

  • Relief valve forces

  • Buildings / supports settlement


Outputs:

The output results are compared with allowable values of pipe material and if stresses or deflection exceeds allowable limits, suitable design modification are suggested to mitigate stresses. The results are presented in pictorially and tabular format in a report showing. :-

  • The stress ratio for the different load combinations.

  • Design modifications like additional supports & their types, if required in piping network, to reduce the stresses.

  • Marked AutoCAD drawings with support locations & additional supports and other design modifications, if required.

  • Forces & Moments acting on each support in all 3 directions.

  • Stress Isometrics for Piping network.

  • Structural steel support for Piping system to sustain various loads.

  • Minor details like base plate calculation, anchor bolt calculation & weld calculation are included in report for different types of supports.

Pipe stress analysis is an analytical method to determine how a piping system behaves based on its material, pressure, temperature, fluid, and support. Pipe stress analysis is not an accurate depiction of the piping behavior, but it is a good approximation. CAESAR II and Bentley-Autopipe software is widely used in the industries.


Located in Calgary, Alberta; Vancouver, BC; Toronto, Ontario; Buena Park, California; We offer our Piping Engineering Services, Skid Design Services, Pipeline Engineering Services and Structural Engineering Services across Canada. To get our Piping Stress Analysis Services, please contact our Engineering company.


Our professional piping stress engineers have a bachelor's and Masters degree in mechanical / structural engineering and province license (P.Eng.) in Alberta, Saskatchewan, British Columbia and Ontario. We review, validate, certify and stamp piping and structural packages. Also check Industries We Serve.


We provide premium piping engineering & full-service pipe design and pipeline / pipe stress analysis services, from initial concept through final construction. We serve all types of industries across Canada & globally. Using CAESAR II and pipe stress calculations as per API, ASME B31.3, B31.1, B31.8, B31.4, B31.9, CSA Z662.
